The Milwaukee® MX FUEL™ equipment system goes beyond the limitations of petrol and corded units, utilising the industry's most advanced batteries, motors, and electronics to deliver the best experience for users. This is equipment, redefined. The MX FUEL™ Handheld Core Drill allows users to core with more confidence through maximum control and enhanced safety with a patented clutch and AUTOSTOP™ technology that prevents over-rotation in case of the machine getting bound up. It delivers the power to core up to 152 mm holes in reinforced concrete while the integrated pressure gauge helps maintain drilling pressure to maximise productivity and runtime. Coupled with the LED level, this ensures easy, accurate holes while handheld. Compatible with the M18™ SWITCH TANK™ 15L Backpack Water Tank Supply with Powered Base, onboard Quick-Connect allows the user to core in both wet and dry applications, as the universal quick-connect hose ensures simple and effective wet coring in the toughest applications. The MX FUEL™ Handheld Core Drill has a compatible Core Drill Stand that is also available (sold separately). The MX FUEL™ Handheld Core Drill is ONE-KEY™ compatible, allowing users to track and manage the tool.

Read More
Book a test drive
from our dedicated Milwaukee Job Site Solutions Team
Specifications What's Included Resources Reviews Related

Specifications

Features

Features

AUTOSTOP™ technology and a patented clutch provide maximum control and prevent over-rotation in case the machine gets bound up
Integrated Pressure Gauge helps provide efficient drilling pressure to maximise productivity and runtime
Onboard water connection allows both wet and dry coring; a universal quick connect hose ensures simple and effective wet drilling in the toughest applications
Power to core 152mm (6") holes in reinforced concrete
Two speed settings, optimised for holes sized 25-76mm and 76-152mm
ONE-KEY™ Tracking & Management
On Board Digital Level & Performance Gauge to Optimise Drilling Zone

Specifications

Specifications

Platform MX FUEL™ / ONE-KEY™
RPM 800 / 1,600
Spindle Size 1-1/4"-7 Spindle Thread
Solid Bit Capacity 152.4mm (6")
ONE-KEY Enabled Yes
Length 548mm
Weight 9.8kg
Warranty 2 Years

What's Included

What's Included

(1) MX FUEL™ Handheld Core Drill [MXFDCD150-0C]
(1) Quick-Connect
(1) Spindle Adaptor
(1) Trigger Lock-On
(1) Side Handle
(1) Carrying Case
(Not Included) Battery and Charger
Milwaukee Redemptions - 1st October - 31st December 2024 Milwaukee Redemptions - 1st October - 31st December 2024

POWER TO CORE UP TO 152MM HOLES IN REINFORCED CONCRETE

Two speed settings optimised for holes sized 25-76mm and 76-152mm

On Board Digital Level & Performance Gauge

Autostop™ & patented clutch

Onboard water connection

arming button

SAFE HANDHELD CORING

AUTO-STOP™ and patented clutch design provide maximum control
and prevent over-rotation in case of bind up

fast set up for versatile coring

Compatible with MX FUEL™ Compact Core Drill Stand (MXFDR150-0)

The MX FUEL™ cordless equipment system is engineered for the most demanding trades, delivering the performance, runtime and durability demanded by professionals, without the hazards associated with noise and vibration. The MX FUEL™ range goes beyond the limitations of petrol and power cords and operates off one completely compatible battery system.
EQUIPMENT REDEFINED. TRADE FOCUSED. SYSTEM WIDE.

SMART TOOL MANAGEMENT STARTS HERE.
DOWNLOAD THE APP TODAY.
