M18 FUEL™ 1/2" High Torque Impact Wrench with Pin Detent (Tool Only)

M18FHIW2P120
  • bvseo_sdk, dw_cartridge, 18.2.0, p_sdk_3.2.0
  • CLOUD, getAggregateRating, 337ms
  • reviews, product
  • bvseo-msg: Unsuccessful GET. status = 'ERROR', msg = 'Not Found.';
M18 FUEL™ 1/2" High Torque Impact Wrench with Pin Detent (Tool Only), , hi-res
M18 FUEL™ 1/2" High Torque Impact Wrench with Pin Detent (Tool Only), , hi-res
M18 FUEL™ 1/2" High Torque Impact Wrench with Pin Detent (Tool Only), , hi-res
M18 FUEL™ 1/2" High Torque Impact Wrench with Pin Detent (Tool Only), , hi-res
M18 FUEL™ 1/2" High Torque Impact Wrench with Pin Detent (Tool Only), , hi-res
M18 FUEL™ 1/2" High Torque Impact Wrench with Pin Detent (Tool Only), , hi-res
M18 FUEL™ 1/2" High Torque Impact Wrench with Pin Detent (Tool Only), , hi-res
M18 FUEL™ 1/2" High Torque Impact Wrench with Pin Detent (Tool Only), , hi-res

M18 FUEL™ 1/2" High Torque Impact Wrench with Pin Detent (Tool Only)

M18FHIW2P120
  • bvseo_sdk, dw_cartridge, 18.2.0, p_sdk_3.2.0
  • CLOUD, getAggregateRating, 337ms
  • reviews, product
  • bvseo-msg: Unsuccessful GET. status = 'ERROR', msg = 'Not Found.';

The M18 FUEL™ ½" High Torque Impact Wrench w/ Pin Detent provides maximum power density and greater access in tight spaces, maximising productivity through faster bolt removal speeds. The POWERSTATE™ Brushless Motor delivers up to 1,220Nm of Fastening Torque and 1,490Nm of Nut-Busting Torque when paired with the M18™ REDLITHIUM™ FORGE™ 6.0Ah Battery, while the compact size at 185.4mm in length gives users greater access in tight spaces. The new battery isolation system provides a secure battery connection and controls vibration transmitted to the pack. Tri-LEDs surround the anvil to deliver brighter light with fewer shadows. 4-Mode DRIVE CONTROL offers greater precision with a range of pre-set RPM and IPM levels, selectable from a single button on the tool. By selecting Mode 4, AUTO SHUT-OFF™ control applies no more than 68Nm of torque for hand-tight fastening applications to prevent overtightening. Mode 4 also features Bolt Removal Mode that delivers users full torque output, then decreases RPMs once the bolt is loosened to prevent fastener drops.

Read More
Specifications What's Included Resources Reviews Related

Specifications

Features

Features

With up to 1,220 Nm of fastening torque and 1,490 Nm of nut-busting torque when paired w/ M18B5 Battery.
At only 185.4mm in overall length the M18FHIW2P120 offers improved access in tight spaces along with a lighter more ergonomic weight when working at heights.
4-Mode DRIVE CONTROL provides greater control over output speeds and power, including AUTO SHUT-OFF and Bolt-Removal Mode.
A new Battery Isolation System provides secure connection and controls vibration transmitted to the battery pack, preventing battery intermittency.
Featuring a on tool tether ring means users can confidently secure the tool when working from heights.

Specifications

Specifications

Platform M18 FUEL™
Voltage 18V
Anvil Type 1/2" Square with Pin Detent
Nut Busting Torque 1,490 Nm
Fastening Torque 1,220 Nm
IPM 0 - 1,400 / 0 - 2,500 / 0 - 2,700 / 0 - 2,700
No Load RPM 0 - 700 / 0 - 1,300 / 0 - 2,000
Drive Control 4 Mode with Auto Shut-Off Mode & Bolt Removal Mode
Length 185.4mm
Weight 2.4 kg
Warranty 5 Years
Torque Level High
Tri-LED Yes
Directional No Load RPM Forwards: 0 - 900;Reverse: 0 - 2,000 / 0- 750

What's Included

What's Included

(1) M18 FUEL™ 1/2" High Torque Impact Wrench with Pin Detent [M18FHIW2P120]
(Not Included) Battery & Charger
